Cassava Grater undergoing installation.
MELON (Egusi) SHELLING/PEELING MACHINE
In order to solve the boredom involved in melon shelling operation which is one of the major factors militating against the large scale production, processing and the use of this important oil crop, a power-driven melon seed shelling machine was designed, constructed and tested.
The machine consists of a feed hopper, a shelling unit, a delivery chute, a power system and a tool frame. The shelling action was achieved by principle of a rotor that throws melon seeds against the shelling drum by centrifugal force and then the seeds were converged onto a spinning disc with vanes that provide impact force to remove the kernel from the shell.
Contact us for more information about this product
MINI COMPACT PALM OIL MILL
These Mini Compact OIL Mill Machines will deliver palm oil of superior quality, with the the machine of high processing efficiency, reliability, and durability equal to any large commercial palm oil mill.
All this at a cost attractive to village organisations, smaller plantation owners, state and local governments, aid agencies, NGO’s, community development projects, etc. we also offer a range of micro/mini-mills with processing capacities from 500 kg ffb/hr up to 1 to 30 tonnes ffb/hr.
All this at a cost attractive to village organisations, smaller plantation owners, state and local governments, aid agencies, NGO’s, community development projects, etc. we also offer a range of micro/mini-mills with processing capacities from 500 kg ffb/hr up to 1 to 30 tonnes ffb/hr.
PALM NUT FIBRE SEPARATOR
The mixture of the palm nuts and fibres is obtained as by product of the palm fruit expeller. It is essential to separate palm nuts from the fibres. It is done in the motor operated machine called nut fibre separator.
It is inclined cylindrical type revolving machine heaving all around suitable size screen from which fibres can escape but palm nuts can not escape. So while travelling the mixture from upper end to lower end of the machine, all the fibres escape from the cylindrical screen while palm nuts are collected from the lower end of the nut fibre separator.
Fibres are used in the boiler as fuel. Palm nuts are sold out to the palm kernel mills where they crack the palm nuts, get the palm kernels, crush the palm kernels and get the palm kernel oil.
PALM FRUIT BUNCH STRIPPER/THRESHER
Palm oil mills receive the palm fruits in the form of palm fruit bunches of 10 to 30 kg. weight. So first operation is to separate the palm fruits from the palm bunches. Separation of palm fruits by hand is very big drudgery.
But OUR palm fruit stripper separates palm fruits from the bunches by easy mechanical process. Stripping operation is done by the beaters welded on all the four sides of revolving heavy square shaft of the stripper.
